KAEN CUT-200 Plasma Cutter with built in Compressor

RM5,880.00

  • KAEN CUT-200 with a built-in maintenance-free air compressor
  • cut capacity of 35mm clean
  • rugged roll-frame design, and generator compatibility
  •  CUT-200 is “go anywhere” plasma cutter, ready to tackle the rigours of any workshop, field or site job
Categories: , Tags: , , Brand:

Product Description

MODEL: KAEN CUT-200 Plasma Cutter with built-in Compressor

FEATURES:
  • Delivers an excellent arc performance;
  • KAEN CUT-200 Plasma Cutter with a built-in maintenance-free air compressor,
  • Over-current protection and overload protection to ensure safety;
  • Ideal for light- and medium-duty daily welding applications;
  • Closed-loop feedback control, built-in fan and ultra-low voltage intelligent regulator, stable output voltage, easy to start in unstable voltage area.
  • An advanced IGBT inverter technology, a high-duty cycle, and an excellent ignition voltage make the welder more reliable and less prone to damage or failure.
  • Energy-saving and highly efficient. The inverter welding machine’s switch also operates fast and uses less energy to do the final operation.
  • An inner cooling fan protects the welding machine from overheating, contributing to the device’s life expectancy.
  • The inner characteristic control; fast system response and quick response to changes in the arc length continuous arc
  • Using the peak current control mode -works reliably even under frequent short circuit impact power device
  • Ideal for welding stainless steel, alloy steel, carbon steel, and other metal materials.
PRODUCT WARRANTY

12 Months

CATALOGUE

Download Here





Technical Specification

Input Voltage (V)

415V±15%,Three, 50/60HZ

Rated Input Power (kVA)

12.5

Output Current Range (A)

30-200

Output @ 60% Duty Cycle

200A

Cutting Thickness (mm)

55mm

Quality Cutting Thickness (mm)

35mm

Process

Air Plasma Cutting

Housing Protection Class

IP21S

Insulation Class

F

Power factor

0.93

Efficiency (%)

80%

Net Weight (kg)

55

Packing Dimension (mm)

480X251X420
